Product Details

The Midmark M9 Steam Sterilizer uses a small footprint to drive big productivity. If space is limited in your steri-center, the M9 makes a good fit. This sterilizer is designed to help optimize your instrument processing workflow while maintaining safe and reliable sterilization. Reliable Steam-flush pressure pulse air removal system ensures proper steam sterilization. Easy to Use Pre-programmed sterilization cycles and intuitive LCD display with prompts ensure quick, confident operation. Safe Real-time alerts notify users promptly of any critical system errors. Specifications: Overall length w/plug: 20.38" (51.8 cm) Overall width: 15.3" (38.9 cm) Overall height w/printer: 16.1 in (40.9 cm) Minimum countertop area: 17.88" D x 15.3" W (45.4 cm x 38.9 cm) Chamber: 9" diameter (22.9 cm) 15" depth (38.1 cm) 3.5 gal usable volume (13.4 liters) Trays: Two large – 7.3" W x 12" L x 0.8" D (18.6 cm x 30.5 cm x 2.2 cm) Two small – 5.6" W x 12" L x 0.8" D (14.3 cm x 30.5 cm x 2.2 cm) Unit weight: 73 lb (33.1 kg) Shipping weight: 81 lb (36.7 kg) Water reservoir capacity: 1.1 gal (4.1 liters) Electrical requirements: 115 VAC, 50/60 Hz, 15 A single phase 115 VAC has 1,425 W tubular immersion heater 230 VAC, 50/60 Hz, 10 A single phase 230 VAC has 1,500 W tubular immersion heater Installation: Use on a level, water-resistant material such as laminate, stainless-steel or stone. Allow 2.0" (5.08 cm) on sides and rear, and 5" (12.7 cm) above to allow space to fill reservoir and change the printer paper roll. Safety standards: UL listed to US and Canada standards UL 61010-1, 2nd edition IEC 61010-2-040, 1st edition CAN/CSA C22.2 No. 61010-1, 2nd edition CSA C22.2 No. 61010-2-040-07, Part 2-040, 1st edition Meets the requirements of ASME Boiler and Pressure Vessel Code. A separate (dedicated) circuit is recommended for this sterilizer. Certifications: IEC 60601-1-2 Edition 4.0 2014-02 CISPR II:2009, A1:2010 Class A, Group 1 IEC 61000-3-2:2014, Part 3-2 IEC 61000-3-3:2014, Part 3-3 ANSI/AAMI ST55:2010(R)2014 ANSI/AAMI/IEC 62304
