Product Details

Features: • Oil free • Quiet operation • Suitable for milling units • Includes moisture trap / filter • Includes 24v start relay Notes: • Includes pressure switch, line pressure gauge, tank pressure gauge and moisture filter. • Dryer not included • Allow 18” around and above for service access and ventilation • Room temperature should range 50 °F -104 °F (10 °C - 40 °C) max. Specifications: Hp: 1.2 hp CFM : 3.8 cfm Operating PSI : 80-145 psi Tank : 6.5 gal Voltage / Amps : 120V / 1 / 60Hz / 15A Decibels : 58 db Dimensions : L35" x D10" x H25" Weight : 56 lbs Site Requirements: Voltage : 230v / 1 ph / 60hz Full Load Amps : 8 amps Breaker Rating : 30 Amps Wire Size : 10 Hp : 1.2 hp BTU / Hour : 1500 @50% duty cycle Install Foot Print : L41" x D16" H31" Shipping Weight : 88 lbs Non-Latex
